Kubota's enrty level diesel utility vehicle range, the RTV-X900 Series offers the ultimate in power and versatility, designed for heavy-duty work in the toughest environments.
Powered by Kubota diesel engines and featuring Kubota's unique Variable Hydrostatic Transmission, the RTV-X900 Series delivers best in class reliability, optimum traction and unrivalled control in rugged terrain.
For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.
Click on the images below to enlarge.
Engine
| Name | RTV-X900G-A | RTV-X900W-A | RTV-X900W-H |
|---|---|---|---|
| Engine Model | Kubota D902 | Kubota D902 | Kubota D902 |
| Fuel Type | Diesel | Diesel | Diesel |
| Cylinders | 3 | 3 | 3 |
| Engine Gross | 21.6 hp | 21.6 hp | 21.6 hp |
| Displacement | 898 cc | 898 cc | 898 cc |
| Fuel Tank Capacity | 30 l | 30 l | 30 l |
| Rated Speed | 3,200 rpm | 3,200 rpm | 3,200 rpm |
Dimensions
| Name | RTV-X900G-A | RTV-X900W-A | RTV-X900W-H |
|---|---|---|---|
| Length | 3,055 mm | 3,110 mm | 3,110 mm |
| Width | 1,605 mm | 1,605 mm | 1,605 mm |
| Height | 2,020 mm | 2,020 mm | 2,020 mm |
| Tread Front | 1,240 mm | 1,240 mm | 1,240 mm |
| Tread Rear | 1,240 mm | 1,240 mm | 1,240 mm |
| Wheelbase | 2,045 mm | 2,045 mm | 2,045 mm |
| Turning Radius | 4 m | 4 m | 4 m |
| Ground Clearance Front | 266 mm | 266 mm | 266 mm |
| Ground Clearance Rear | 263 mm | 263 mm | 263 mm |
| Weight | 865 kg | 865 kg | 865 kg |
| Towing Capacity | 590 kg | 590 kg | 590 kg |
| Payload Capacity | 755 kg | 725 kg | 725 kg |
