This long bed model holds true to the legacy of the RTV-X Series; powered by Kubota's D1105 Diesel Engine, paired with VHT-X transmission, hydraulic dump box and power steering; features that have made the X-Series so popular.
With it comes a suite of new features like Pro-Konvert functionality and new cargo box accessories, that represent capability re-imagined. No matter what job you have to get done, or how you like to spend your free-time, the RTV-X1130 is built to outwork!
For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.
Click on the images below to enlarge.
Engine
| Name | RTV-X1130 |
|---|---|
| Engine Model | Kubota D1105 |
| Fuel Type | Diesel |
| Cylinders | 3 |
| Engine Gross | 24.8 hp |
| Displacement | 1,123 cc |
| Fuel Tank Capacity | 30 l |
| Rated Speed | 3,000 rpm |
Dimensions
| Name | RTV-X1130 |
|---|---|
| Length | 3,925 mm |
| Width | 1,605 mm |
| Height | 2,025 mm |
| Tread Front | 1,280 mm |
| Tread Rear | 1,280 mm |
| Wheelbase | 2,495 mm |
| Turning Radius | 5.2 m |
| Ground Clearance Front | 293 mm |
| Ground Clearance Rear | 257 mm |
| Weight | 1,060 kg |
| Towing Capacity | 590 kg |
| Payload Capacity | 754 kg |
