Powered by Kubota’s 24.8HP engine and featuring Kubota’s unique Variable Hydrostatic Transmission, the RTV-X Crew delivers best in class control on rugged terrain.
Experience exceptional versatility with the RTV-X Crew's unique design, allowing you to change easily from transporting materials to diving more passengers with a convenient second row of seating.
For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.
Click on the images below to enlarge.
Engine
| Name | RTV-X1140W |
|---|---|
| Engine Model | Kubota D1105 |
| Fuel Type | Diesel |
| Cylinders | 3 |
| Engine Gross | 24.8 hp |
| Displacement | 1,123 cc |
| Fuel Tank Capacity | 30 l |
| Rated Speed | 3,000 rpm |
Dimensions
| Name | RTV-X1140W |
|---|---|
| Length | 3,610 mm |
| Width | 1,605 mm |
| Height | 2,025 mm |
| Tread Front | 1,280 mm |
| Tread Rear | 1,280 mm |
| Wheelbase | 2,495 mm |
| Turning Radius | 5.2 m |
| Ground Clearance Front | 285 mm |
| Ground Clearance Rear | 240 mm |
| Weight | 1,075 kg |
| Towing Capacity | 590 kg |
| Payload Capacity | 739 kg |
