Powered by Kubota 3 and 4 cylinder diesel engines, depending on the model, and HST Plus transmission, the L40 Series delivers high performance and professional results for tasks both small and large.

Expect top of the line features, including Intelli-Panel, Kubota’s unique tractor monitoring system and luxury reclining seating for ease of operation and comfort during those long hours of operation. Available with a number of attachments, you will come to rely on Kubota's Premium L40 Series, boosting your versatility, efficiency and productivity.

Get Finance
View Specs

DOWNLOAD BROCHURES

Kubota_Tractor_L3540_L4240_L5740

TALK TO A SALESPERSON

This field is required
This field is required
This field is required Not a valid number!
This field is required This is not a valid email.
reCAPTCHA is required

For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.

Model Specifications


Engine

Name L3540HDA L5740HDA L5740HDCA L4240HDA L4240HDCA
Fuel Type Diesel Diesel Diesel Diesel Diesel
Cylinders 3 4 4 4 4
Engine Model Kubota D1803 Kubota V2403 Kubota V2403 Kubota V2203 Kubota V2203
Engine Gross 35 hp 57 hp 57 hp 42 hp 42 hp
PTO 28 hp 50.7 hp 50.7 hp 35 hp 35 hp
Displacement 1,826 cc 2,434 cc 2,434 cc 2,197 cc 2,197 cc
Fuel Tank Capacity 44 l 54 l 54 l 50 l 50 l
Rated Speed 2,700 rpm 2,700 rpm 2,700 rpm 2,700 rpm 2,700 rpm



Dimensions

Name L3540HDA L5740HDA L5740HDCA L4240HDA L4240HDCA
Length 2,960 mm 3,210 mm 3,210 mm 3,085 mm 3,085 mm
Width 1,520 mm 1,710 mm 1,710 mm 1,690 mm 1,690 mm
Height 2,390 mm 2,490 mm 2,405 mm 2,400 mm 2,290 mm
Wheelbase 1,805 mm 1,915 mm 1,915 mm 1,895 mm 1,895 mm
Ground Clearance 350 mm 400 mm 400 mm 375 mm 375 mm
Turning Radius 2.7 m 2.8 m 2.8 m 2.7 m 2.7 m
Tractor Weight 1,540 kg 1,770 kg 1,920 kg 1,665 kg 1,815 kg
