The performance begins with a reliable and efficient Kubota engine that can power through even the toughest tasks with ease and speed. There’s plenty of power for PTO-driven implements, as well as convenient electronic speed control to keep those implements operating at optimum efficiency. A fully synchronised transmission and an advanced hydraulic shuttle for shifting between forward and reverse simplifies tractor operations.

An all-glass cab and a newly designed bonnet ensure excellent visibility in all directions, including both front and rear implements as well as the immediate working environment. The cab glass is curved to reduce glare and enhance spaciousness, while narrow pillars and a sloping bonnet increase visibility in all directions.

Get Finance
View Specs

DOWNLOAD BROCHURES

Kubota_Tractor_M5091_M5101_M5111

TALK TO A SALESPERSON

This field is required
This field is required
This field is required Not a valid number!
This field is required This is not a valid email.
reCAPTCHA is required

For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.

Model Specifications


Engine

Name M5091DHC M5111DHC M5111DHC-DS M5091DH M5111DH
Fuel Type Diesel Diesel Diesel Diesel Diesel
Cylinders 4 4 4 4 4
Engine Model  Kubota V3800 Kubota V3800 Kubota V3800 Kubota V3800 Kubota V3800
Engine Gross 93 hp 110.5 hp 110.5 hp 93 hp 110.2 hp
PTO 75 hp 88 hp 88 hp 75 hp 85.5 hp
Displacement 3,769 cc 3,769 cc 3,769 cc 3,769 cc 3,769 cc
Fuel Tank Capacity 105 l 105 l 105 l 105 l 105 l
Rated Speed 2,600 rpm 2,600 rpm 2,600 rpm 2,600 rpm 2,600 rpm



Dimensions

Name M5091DHC M5111DHC M5111DHC-DS M5091DH M5111DH
Length 3,955 mm 3,955 mm 3,750 mm 3,045 mm 3,955 mm
Width 2,005 mm 2,005 mm 2,005 mm 1,990 mm 2,005 mm
Height 2,650 mm 2,650 mm 2,650 mm 2,680 mm 2,650 mm
Wheelbase 2,250 mm 2,250 mm 2,250 mm 2,250 mm 2,250 mm
Ground Clearance 520 mm 520 mm 520 mm 520 mm 520 mm
Turning Radius 3.8 m 3.8 m 3.8 m 3.8 m 3.8 m
Tractor Weight 3,220 kg 3,220 kg 3,220 kg 2,790 kg 2,790 kg
